Poultry Farm Equipment Stainless Steel Valve Plug Nipple Pig Water Drinkers
Features:
G-1/2" Thread (European pipe thread) or NPT-1/2" (American pipe thread) is favorable.
Body length 31mm.
Pressure cone diameter 18.5mm.
Weight 57g.
With diameter 8mm pin.
Adjustable plastic filter with stainless steel netting.
Adjustable plastic filter is easy to change high pressure water systems and low pressure water systems.
NBR 90 O-ring is permanent and protect leaking.
Specs:
1) Under group feeding, every 10 pigs are allocated with one drinking equipment, and the flow rate selection depends on the pig body size.
2) When using the drinking trough, in order to save water, it is suggested to also install water level control valve. A water level control valve is designed for every 15 sows.
3) The drinking equipment needs to be installed with a certain angle(30-45 degree).
4) In the pressure range of 0.2-6 bar, the flow rate remains constant. With constant flow, pigs can get more comfortable drinking water.
There are many varieties of drinking water and including sucking valve, water valve, bowls drinkers and so on which is suitable for different stage of pig drinking water. Stainless steel valve body and stainless steel spring is long life with adjustable water supply. Equipped with 30, 60 and 90 degree elbow adapt to the different drinking angle and height of pigs and can fully meet the drinking water demand of the pigs, so that the pigs can get enough water.
Component
The duckbill pig drinking water equipment mainly consists of a valve body, a valve core, a sealing ring, a return spring, a plug cover and a filter screen. The valve body and the valve core are made of brass and stainless steel, the spring and the filter mesh are made of stainless steel, and the plug cover is made of engineering plastic.
Use Method
When the pig drinks water, the mouth contains a drinking fountain, bite the valve stem, and the water flows out from the gap between the valve core and the sealing ring, and enters the pig's mouth. When the pig's mouth is released, the spring tension is returned, the valve stem is reset, and the water gap is It is closed and the water stops flowing.
Product Information
| Name | Pig Water Drinkers |
| Model | NP-810 |
| Length | 31mm |
| Stem | 18.5x8mm |
| Weight | 57g |
| Inlet | G - 1/2’’ thread or NPT - 1/2’’ is favorable |
| LOGO | Laser logo or stamping logo is favorable |
| O-ring | NBR 90 |
| Shape | Straight, (45, 90, 70) degrees, T shape, two way type, long type, square type and other special customized type |
| Surface | Zinc (chrome, copper and nickel are available) |
| Main of material | Carbon steel, mild steel, brass etc. |
| Package | 1. Inner packing: OPP bags, 100pcs/bag with a sticker, stickers can be printed as per buyer's requirements 2. Outer packing: standard export cardboard cartons and reinforced with straps 3. Other customized packing ways negotiable |
| MOQ | 1000PCS |
| Payment | T/T |
Pictures
Package
FAQ
Q1.Can you offer free sample?
A: Yes, but express fee should be paid by customer
Q2. Are you the manufacturer?
A:YES, we are professional manufacturer of poultry equipment products.
Q3. Can i customize the products?
A:Yes,we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q4. How about the delivery time
A: Generally, it will take 15-45 days after receiving your advance payment. Sample 2-5days delivery
Q5. What is your terms of packing?
A: Generally, we pack our goods in brown cartons. if you have special requirement, it can be according to customers' request
Q6. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefit ;
2. We have many farmer friends to provide you with breeding experience. Welcome to visit the poultry house and our factory.
